120v solar charge controller 30a solar charge controller

Attention:

1. If your address is remote area by DHL or FedEx, then we will send by other express

2. We can low down some price for less customs duty when shipping, please leave the value of product you want us to declare, otherwise,we will declare by our experience; and we will not bear the high tariff cost,buyer must bear the reponsibility by themselves.

3. The Customers from Brazil please must leave CPF number or CNPJ number, otherwise, the shipping company will refuse the transport;

General Description

The solar charge controller is the intelligent device with integration of controlling. It has good running performance with LCD display and convenient operation. Also have multi protection functions such as over-charge, over-discharge protection, and pole-confusion protection for storage battery. The controller is adopted PWM charging mode. It has high reliable and safe operation, high efficiency, long service life functions.

Performance Feature

lControl using common positive polarity way, accept 2 lines input of solar array.

lDigital design, module structure, quite be stable and reliable.

lLCD equipped (backlighting) to show parameters of system running status.

lHigh efficiency with by PWM charging method.

lAnti-reverse connection, no charging reversely while night. And Over-charge, limited charging current &voltage protections   for battery.

lUser can adjust setting of system parameters as over-charge voltage, recovery charging voltage, and so on.

lEquipped with data communication function (optional)

lDay and night double process mode for saving energy.

lWall mounting type be easy to fix.

1 Device outline

2 LCD showing illumination

1.----- LCD with green backlight to display battery voltage(V) and charging current(A), bottom of line is showing will show “STATE: Normal” while battery be normal, if battery at high volume will showing, STATE: OVER VOLTS", if battery is under level will show, STATE: LOW VOLTAGE". And battery power volume with percent.

 2. ----- "Enter” key to process setting condition or save modification of parameters.

3.-----  this key is using to browse status data of system and set value of parameters for increasing.

4. ---- this key is using to browse status data of system and set value of parameters for reducing.

5.---- "Esc" key for existing system without save setting.
